HARL Actuator
HARL Satellite Actuator
★ Features
Adjustable stroke
Reed sensor
Acme screw
Self-loc
Commodity information
HARL Satellite Actuator
★ Features
Adjustable stroke
Reed sensor
Acme screw
Self-locking
Water & dust resistant
Enhanced antirust quality
High performance & service life
High precision
Option
Stroke length: 6"/ 8"/ 12"/ 18"/ 24" (inch)
Voltage : 24 /36 VDC
Sensor type : Reed
Drive screw : Acme
★ Rating
Operating temperature: from -15 to 40℃
★ Spec.
Actuator Type Rod type
Stroke length 24"18"12"
Optimal stroke 21"～23"15"～17"9.5"～11.2"
Static Load 4,000 N
Load capacity 1,000N
Dynamic load 2,500 N
Speed(Non-load) 7.8mm/sec.
Resolution 1.26 pulse/mm
Input Voltage 36VDC
Load current≤0.80A
Duty cycle 20%
★Packaging
Packing spec. 90.5x21.5x17.5(cm)
Weight 21.18 kgs/4pcs
